Itel Energy 16000Wh Lithium Battery Standing 48V 314Ah

Description

The itel Energy IPL-51314H is a high-capacity LiFePO₄ lithium battery designed for large residential, commercial, and industrial solar energy-storage systems. It provides approximately 16.07kWh of nominal energy and is designed for 48V battery systems.

Key Specifications

• Model: IPL-51314H
• Battery Type: LiFePO₄ (Lithium Iron Phosphate)
• Nominal Voltage: 51.2V
• Capacity: 314Ah
• Energy Capacity: 16.07kWh / 16,070Wh
• Operating Voltage: 43.2V–57.6V
• Maximum Continuous Charge: 157A
• Maximum Continuous Discharge: 157A
• Peak Charge: 175A
• Peak Discharge: 175A
• Recommended DoD: 90%
• Cycle Life: 6,000+ cycles
• Active Balancing: 5A
• BMS: Intelligent Battery Management System
• Communication: Supports inverter communication
• Installation: Floor/standing
• Protection Rating: IP21 — indoor use
• Dimensions: 820 × 550 × 232mm
• Weight: Approximately 120kg
• Operating Temperature: -20°C to 60°C discharge
• Parallel Expansion: Up to 32 units
• Design Life: Up to 10 years

What It Can Power

With a properly sized 48V hybrid inverter, this battery can support:

• Air conditioners
• Refrigerators
• Freezers
• TVs
• Fans
• Lighting
• Washing machines
• Water pumps
• Computers
• Routers
• Microwaves
• Kitchen appliances
• Office equipment

Ideal Applications

Large homes • Estates • Hotels • Hospitals • Offices • Shops • Schools • Farms • Data centers • Commercial buildings • Off-grid solar systems

The 16kWh capacity makes it particularly suitable where longer backup runtime is required
