itel Energy 50kW 3-Phase Hybrid Inverter

Description

The itel Energy IHY-50KH3S is a commercial and industrial 50kW / 50kVA 3-phase hybrid inverter designed for large solar installations, factories, offices, hotels, hospitals, estates and other high-power applications. It supports up to 75kW of solar PV and high-voltage lithium batteries from 150–840V DC.

Key Specifications

☀️ Solar Capacity

The inverter accepts up to 75kW of solar panels, giving it a 160% DC oversizing capability. With 4 MPPTs and 2 strings per MPPT, it is designed for large solar arrays.

For example:

• 100 × 620W panels = 62kW
• 120 × 620W panels = 74.4kW
• 125 × 620W panels = 77.5kW — this exceeds the stated 75kW PV input and therefore should not be used at full rated input without confirming the manufacturer’s configuration limits.

🔋 Compatible Battery System

The IHY-50KH3S uses high-voltage lithium batteries, not a conventional single 48V battery bank. It accepts 150–840V DC and supports up to 50kW battery charging/discharging power.

For the itel C&I system, the 16kWh / 51.2V 314Ah IPX-51314SPT battery can be configured in series to create a high-voltage battery bank. The current itel documentation gives configurations such as 12 batteries in series = 614.4V nominal and approximately 192kWh.

⚡ What Can It Power?

A properly designed 50kW system can support:

• Factory machinery
• 3-phase motors
• Air compressors
• Industrial pumps
• Borehole pumps
• Central air-conditioning systems
• Cold rooms
• Industrial freezers
• Hotels
• Hospitals
• Office buildings
• Shopping plazas
• Elevators
• Data/server rooms
• EV charging equipment
• Petrol station equipment
• Large residential estates

The actual appliances that can operate simultaneously depend on their combined running power, starting/surge requirements and the battery/PV configuration.

🏭 Major Features

100% Unbalanced 3-Phase Output
The inverter is designed to handle different loads on the three phases, which is useful for commercial installations with uneven phase loading.

Diesel Generator Support
It supports generator integration for installations requiring multiple energy sources.

Up to 10 Units in Parallel
Multiple units can be connected to scale the system up to approximately 500kW.

IP66 Protection
The enclosure is rated IP66 for demanding indoor and outdoor commercial environments
